500KVA as per require 30-500KVA
Technical Specifications
- System Connections : Delta/ Star
- Input Voltage : 415V 3 Phase
- Output Voltage : 415V or 200V 3 Phase
- Ratios : 1:l and 2:1
- Regulation : Better than 3.5 %
- Power Factor : 0.75 Lead to 0.75 Lag
- Di-electric Strength : 3 KV for 60 sec
- Insulation Resistance : Better than l000Mega Ohms
- Coupling Capacitance : 0.1 PF for 80db
- Leakage Current : Less than 20 Micro Amps
- Common Mode Attenuation : 80db/100db
- Construction Standards : As per IS 2026 Part I & II, IS 11171
- Type of Execution : Closed Type
- Operating Temperature : 0C to 45C
- Type of cooling : Natural air/ Forced air Oil cooled (optional)
Most Suitable for
CNC Machines
Bio Medical Equipments
Printing Machineries
Cell Phone Networks
Scientific Equipments
Textile Machineries
Oil & Vanaspathi Plants
Large Computer Installations
Garment Equipments
…and many more
Features
- Eliminates stresses that come from normal electrical transients
- Meet stringent clean power requirements of the sophisticated /sensitive equipments
- Reduces the effects of power line problems like Noise, Spikes, Surges, Transients and Neutral to minimum
